PF400

Cooling and Ventilation

Typical Airflow :
3500m3/hr
Voltage Requirements :
110/230
PF400

• Cooling
• Ventilation
• Extraction
• Long Distance

Welcome to the PF400, the first heavy duty power ventilator to be designed and built specifically to the hire industry standards. With it's rugged construction and unique long distance ducting capability, it's the ideal choice for the hire fleet manager.

PF400 PF400
Part Number 1092630 1092640
Height (mm) 355 355
Width (mm) 363 363
Depth (mm) 350 350
Weight(kgs) 19 19
Voltage 110 230
Current (A) 3 3
Power (kW) 0.55 0.55
Supply Fuse Rating (A) 13 13
Recquired Generator Size (kva) 1 1
Airflow (m3/hr) 3500 3500
Static Pressure (mm/wg) 40 40
Blade Diameter (mm) 280 280
Duct Diameter (mm) 35 35
PF400 PF400
Part Number 1092630 1092640
On/Off Control Y Y
Speeds 1 1
Balanced Carrying Handle Y Y
Light Weight Construction Y Y
Finger Guards Y Y
Anti Skid Feet Y Y
Cable Wrap Y Y
Fitted Plug Y N
Stoved Epoxy Finish Y Y

300mm Diameter Flexible Duct - 5m Long (Part Number: 2092675)

PF400

1x PF400 Airmover
1x PF400 Owners Manual

The Versatile Air Movement System

Whatever the application, the Ebac PF400 has the capacity your customers need. Wherever adverse environmental conditions pose a threat to health, safety and efficiency, the PF400 ventilator can be used in one of three ways to improve air quality.

Cooling

Hot and humid conditions are uncomfortable and lead to reductions in work force efficiency. By introducing a constant flow of fresh air, the PF400 ensures that even the hottest areas become cool and comfortable.

Ventilation

Conditions in crowded of poorly ventilated rooms are unpleasant and unhealthy. A lack of oxygen in the air causes drowsiness, making operation of machinery dangerous. An Ebac PF400 can ensure a constant supply of fresh oxygen-rich air.

Extraction

In areas where fumes, dust or unpleasant smells prevail, the build-up can be a risk to health and safety. The PF400 has the power to extract huge amounts of contaminated air through it's heavy duty, non-coilapsable flexible ducting.

Total Flexibility

The PF400 is the most versatile air movement system available. It can be used as a stand alone fan for high capacity comfort cooling or in conjunction with a duct, to inject fresh air or extract contaminated air. By joining a series of ducts and fans together, the PF400 can be used to extract or replenish air over considerable distances.

Built to Last

Like all Ebac hire shop equipment, the PF400 is built to rigorous hire industry standards. It’s robust, welded steel construction guarantees exceptional rapid payback and many years of revenue generating service.
